Type QJ71LP21G, QJ72LP25G, QJ71LP21GE and QJ72LP25GE
MELSECNET/H Network Modules
Type Q80BD-J71LP21G and Q80BD-J71LP21GE
MELSECNET/H Interface Boards
Product configuration
| Product Name | Type | Remarks |
| Type Q80BD-J71LP21G MELSECNET/H Interface Board | Q80BD-J71LP21G | Q80BD-J71LP21G x 1 CD-ROM (SW0DNC-MNETH-B) x 1 Manual x 1 Software license agreement x 1 |
| Type Q80BD-J71LP21GE MELSECNET/H Interface Board | Q80BD-J71LP21GE | Q80BD-J71LP21GE x 1 CD-ROM (SW0DNC-MNETH-B) x 1 Manual x 1 Software license agreement x 1 |
[Features]
1. QJ71LP21G, QJ72LP25G, QJ71LP21GE, QJ72LP25GE
(1) Using of GI optical fiber cable with the above new modules provides maximum distance of 2 km between
stations, whereas the previous modules could achieve only 1 km.
(2) Data from conventional systems can be utilized.
The performances and specifications of the modules are the same as those of the former types
(QJ71LP21-25 and QJ72LP25-25), except for the distance between stations and the communication speed.
You can utilize the parameters of conventional systems.
2. Q80BD-J71LP21G, Q80BD-J71LP21GE
(1) Using of GI optical fiber cable with the above new modules provides maximum distance of 2 km between
stations, whereas the previous modules could achieve only 1 km. Please note that the modules can construct
only PLC to PLC network.
(2) Data from conventional systems can be utilized.
The performances and specifications of the modules are the same as those of the former types
(Q80BD-J71LP21-25), except for the distance between stations and the communication speed. You can
utilize the parameters and user applications of conventional systems.
Manuals
| Manual name | Manual shipment form | IB/SH No. | Type code |
| MELSECNET/H Network Module User’s Manual (Hardware) QJ71LP21-25,QJ71LP21G,QJ71BR11 | Enclosed with product | IB-0800144-B | 13JT16 |
| MELSECNET/H Network Module User’s Manual (Hardware) QJ72LP25-25,QJ72LP25G,QJ72BR15 | Enclosed with product | IB-0800145-B | 13JT17 |
| MELSECNET/H Network Module User’s Manual (Hardware) QJ71LP21GE,QJ72LP25GE | Enclosed with product | IB-0800183-A | 13JR34 |
| Q Corresponding MELSECNET/H Network System Reference Manual (PLC to PLC network) | Sold separately | SH-080049-C | 13JF92 |
| Q Corresponding MELSECNET/H Network System Reference Manual (Remote I/O network) | Sold separately | SH-080124-B | 13JF96 |
